Ki fèt pou jere tanperati inlet ki wo jiska 80 degre.
Segondè efikasite tout-an-yon sèl konsepsyon echanjeur chalè pèmèt sechwa nou yo pwa limyè ak ti enprime pye.
Frijidè HFC zanmitay anviwònman an R134a ak R407C.
Mwens pwen nan soude, pi ba risk flit.
Gwo konsepsyon pre-cooler & kontwa koule, ekonomize enèji jiska 25%.
Demister dlo séparateur, 99+% efikasite pwen lawouze garanti, anpil pi bon pase siklòn séparateur.
Konpresè rezistan èrmetik refrijerasyon bay ane nan sèvis gratis.
Sistèm kontwòl otomatik tanperati refrijerasyon kenbe egzak tanperati lè frèt.
Izolasyon bò refrijerasyon pou ekonomize enèji.
Divès ekipman pou pouvwa pou opsyon.
Espesifikasyon teknik
| Modèl | AirKoneksyon | Kapasitem³/min | Ekipman pou pouvwa | Absòbe | Dimansyon mm | Pwa | |||
| Pouvwa (kW) | |||||||||
| m³/min | CFM | V/Ph/Hz | L | W | H | KG | |||
| RSLF-12-HT | Rc1/2" | 1.2 | 42 | 230/1/50 | 0.3 | 650 | 320 | 550 | 35 |
| RSLF-24-HT | Rc1" | 2.4 | 85 | 230/1/50 | 0.61 | 800 | 420 | 600 | 70 |
| RSLF-30-HT | Rc1" | 3 | 106 | 230/1/50 | 0.76 | 800 | 420 | 600 | 75 |
| RSLF-60-HT | Rc1-1{/2" | 6 | 212 | 230/1/50 | 1.09 | 750 | 695 | 1260 | 125 |
| RSLF-80-HT | Rc1-1{/2" | 8 | 282 | 230/1/50 | 1.45 | 750 | 695 | 1260 | 128 |
| RSLF-100-HT | Rc1-1{/2" | 10 | 353 | 230/1/50 | 1.82 | 750 | 695 | 1260 | 133 |
| RSLF-120-HT | Rc2" | 12 | 424 | 230/1/50 | 2.18 | 1000 | 840 | 1450 | 165 |
| RSLF-150-HT | Rc2" | 15 | 530 | 230/1/50 | 2.73 | 1000 | 840 | 1450 | 175 |
|
Kondisyon Rated |
|
|
Travay presyon: 0.7MPag / 100psig |
|
|
Tanperati Inlet: 60 degre / 140 ℉ |
|
|
Tanperati anbyen: 38 degre / 100 ℉ |
|
|
Ranje travay |
|
|
Max. presyon k ap travay: 1.5MPag / 218psig |
|
|
Max. Tanperati inlet: 80 degre / 176 ℉ |
|
|
Max. Tanperati anbyen: 50 degre / 122 ℉ |
|
|
Min. Tanperati anbyen: 5 degre / 41 ℉ |
|
|
Disponib |
|
|
Pi wo presyon k ap travay |
|
|
Diferan ekipman pou pouvwa |
|
|
Drenaj kwonometre oswa drenaj zewo pèt |
|
|
Pi wo Kapasite |
Faktè Koreksyon
Kapasite aktyèl (m³/min)=Kapasite nominal × KA × KB × KC
| Presyon travay (KA) | Mpag | 0.4 | 0.5 | 0.6 | 0.7 | 0.8 | 0.9 |
| psig | 58 | 73 | 87 | 102 | 116 | 131 | |
| CFP | 0.86 | 0.92 | 0.93 | 1 | 1.04 | 1.08 | |
| Mpag | 1 | 1.1 | 1.2 | 1.3 | 1.4 | 1.5 | |
| psig | 145 | 160 | 174 | 189 | 203 | 218 | |
| CFP | 1.11 | 1.15 | 1.18 | 1.22 | 1.25 | 1.28 |
| Tanperati Inlet (KB) | degre | 50 | 55 | 60 | 65 | 70 | 75 | 80 |
| ℉ | 122 | 131 | 140 | 149 | 158 | 167 | 176 | |
| CFT | 1.03 | 1.02 | 1 | 0.87 | 0.78 | 0.7 | 0.64 |
| Tanperati anbyen (KC) | degre | 25 | 30 | 35 | 38 | 40 | 45 | 50 |
| ℉ | 77 | 86 | 95 | 100 | 104 | 113 | 122 | |
| CFT | 1.15 | 1.1 | 1.02 | 1 | 0.89 | 0.79 | 0.69 |
